Overview

The Hot Diesel Pressure Cleaner is a Yanmar powered hot water machine rated at 2900 PSI and 16 litres per minute, manufactured in Italy. A Yanmar 10HP diesel engine with electric start drives a Comet plunger pump through a gearbox at 1400 RPM, with an external unloader valve. The machine is built on a black powder coated 4 wheel roll frame.

This is a well presented diesel hot water machine for sites without mains power. The double coil vertical boiler with a stainless steel outer casing heats the water, the electronic temperature setting keeps it at a constant temperature, and the flow switch operated burner fires only when water is flowing, which saves fuel.

Key Features

• Yanmar 10HP diesel engine with electric start
• Comet plunger pump, external unloader valve
• 2900 PSI at 16 litres per minute
• Gearbox drive at 1400 RPM
• Double coil vertical boiler with stainless steel outer casing
• Electronic temperature setting for constant water temperature
• Automatic decelerator reduces RPM in bypass phase
• PED 97/23/CE category II certification

Specifications

• Performance: 2900 PSI at 16 L/min
• Engine: Yanmar 10HP electric start
• Pump: Comet plunger pump
• Unloader: external, gradual pressure restoration
• Drive: gearbox, 1400 RPM
• Boiler: double coil vertical, stainless steel outer casing
• Fuel tank with level float and fill up filter
• Country: manufactured in Italy
• Accessories: 15 m of hose, 4 quick nozzles, gun and lance

Applications

• Truck and plant degreasing with hot water
• Industrial equipment and machinery cleaning
• Mine and construction site washdown
• Fleet maintenance and contract cleaning
• Sites with no mains power

What You Need to Complete the Job

Run the delivery line through a 92 metre hose reel and carry single wire high pressure hose for replacement lengths. Service the engine with Penrite SAE 30 small engine oil, and see the Pressure Washers Accessories range for the rest of the kit.

Frequently Asked Questions

Why choose a hot diesel machine?

Hot water breaks down grease and heavy grime far faster than cold water, and a diesel machine runs where there is no power point. That combination suits fleet, plant and mine site cleaning, where the machine has to travel to the work and the grime is tough.

How is the water temperature controlled?

The listing states an electronic temperature setting system that releases water at a constant temperature, with a flow switch operated burner that fires when water is flowing. The automatic decelerator also drops the engine RPM in the bypass phase, which saves fuel when the trigger is released.

Is the boiler certified?

The listing states PED 97/23/CE category II certification for the boiler. It also carries a safety valve and boiler thermal protection, so the hot water system is protected against over pressure and overheating.
