Overview

The Hot 13HP Belt Drive Pressure Washer pairs a professional quality Honda GX390 engine with a commercial grade General triplex pump, delivering 4000 PSI at 15 litres per minute. The belt drive system keeps the pump speed low, which lowers heat, vibration and RPM to extend pump life. A 55AH marine battery is included with the machine.

The diesel burner is ignited by a 12 volt Becker burner and controlled by an adjustable thermostat up to 93C, with an output of 330,000 BTU. The powder coated steel frame carries four 13 inch flat free tires for stability on rough terrain, and a lift point is built into the frame so the machine can be craned onto a truck or trailer.

Key Features

• Honda GX390 13HP engine with electric start, 55AH marine battery included
• Belt drive system for longer pump life
• Commercial grade General triplex pump
• 4000 PSI at 15 litres per minute
• External unloader for cooling and versatility
• Diesel burner with adjustable thermostat to 93C, 330,000 BTU output
• Powder coated steel frame, four 13 inch flat free tires
• Brass air fitting to blow out the coil with an air compressor

Specifications

• Max temperature: 93C / 200F
• Pump style: triplex, external unloader
• Series: industrial
• Engine: Honda GX390, 389cc
• Pump: General
• Pressure: 4000 PSI, flow 4.0 GPM
• Frame: powder coated steel, roll cage, 4 x 13 inch flat free tires
• Included: 50 ft high pressure hose, spray gun wand assembly, 5 spray nozzles, 12 inch oil drain hoses

Applications

• Truck and trailer mounted hot water cleaning
• Industrial equipment and machinery degreasing
• Construction plant washdown
• Fleet maintenance and workshop cleaning
• Heavy grime building washdown

What You Need to Complete the Job

Run the delivery line through a 92 metre hose reel and carry single wire high pressure hose for replacement lengths. Service the engine with Penrite SAE 30 small engine oil, and see the Pressure Washers Accessories range for the rest of the kit.

Frequently Asked Questions

Why is belt drive better for the pump?

A belt drive runs the pump at a lower speed than the engine, which reduces heat, vibration and RPM. The listing states this provides the longest possible pump life. Lower pump speed is the standard way commercial machines protect an expensive triplex pump.

Is the battery included?

Yes. A 55AH marine battery is included with the machine, so the electric start is ready to go. The 12 inch oil drain hoses also make oil changes easier and cleaner.

How is the burner controlled?

The diesel burner is ignited by a 12 volt Becker burner and controlled by an adjustable thermostat that can be set up to 93C. The listing states an output of 330,000 BTU, and the burner can be turned off and controlled from the thermostat.
