Universal Roof Hook

The universal roof hook is a stainless steel bracket that anchors solar panel rails, conduit and small rooftop hardware to roof battens without drilling through the tiles. It is made from SUS 304 stainless steel, with the flange bolts included, and the top and bottom of the hook adjust to suit the tile profile. Because it wraps around the batten, it works on flat, S-tile, Roman and Spanish profiles with no custom hook required.

Key Features

• SUS 304 stainless steel with flange bolts included
• Dual-adjustable: top +/- 55mm and bottom +/- 10mm
• Anchors around the batten, no tile drilling needed
• Suits flat, S-tile, Roman and Spanish profiles
• Connects to standard M8/M10 solar rail systems
• Expected life of about 20 years, backed by a 20 year warranty

Specifications

• Material: SUS 304 stainless steel
• Adjustability: top +/- 55mm, bottom +/- 10mm
• Weight: approx. 0.83kg each including hook, base plate, bolts and nuts
• Corrosion resistance: ISO, CE, SGS, AS/NZS, JIS, ASCE7 compliant
• Finishes: natural stainless or optional black coating
• Packaging: individual or bulk packs

Installation

Position the hook on the batten above the roof tile and secure the base plate with the supplied wood screws. Adjust the top and bottom hook heights to fit the tile profile, then attach the solar rail using M8 or M10 bolts and T-nuts. Because the hook clamps around the batten rather than drilling the tile, the roof tiles stay intact and the mounting is fully adjustable during the fit.

Applications

• Solar PV panel rail mounting on tiled or metal roofs
• Cable trays, conduit and small rooftop hardware anchor points
• Flat, S-tile, Roman and Spanish tile profiles
• Standard M8/M10 rail systems with included bolts and T-nuts

What You Need To Complete The Job

Roof work needs the right access equipment, so pair the hook with a ladder grip to secure your ladder on the roof. Finish the roof after the install with the ridge cover. Browse the Roofing Accessories range for more.

Frequently Asked Questions

Does the hook require drilling into the tiles?

No. The hook anchors around the roof batten, so the tiles stay intact. That keeps the roof watertight and avoids the cracks and leaks that come from drilling through tile.

What tile profiles does it fit?

The top and bottom of the hook adjust, so it suits flat, S-tile, Roman and Spanish profiles. The adjustment range is +/- 55mm on top and +/- 10mm on the bottom, which covers most common tile shapes and thicknesses.

What material is it made from?

It is made from SUS 304 stainless steel, which resists rust and corrosion in outdoor conditions. The flange bolts are included, and the finish is natural stainless with an optional black coating.

How much weight does it carry?

The hook is built for solar panel rail mounting and small rooftop hardware, and it is rated for a long service life of about 20 years with a 20 year warranty. Match the number of hooks to your rail system’s load requirements.

Can I order for delivery or pickup?

Yes. You can order online and choose Australia-wide delivery or pickup from our Truganina trade counter in Melbourne’s west. Delivery windows depend on your postcode, and we send a confirmation once your order is ready. For any questions call (03) 93941400 or email orders@singhroofingsupplies.com.au.
