Bailey Modular Access 2.0m Platform 200kg

The Bailey FS13790 Modular Access System 2.0m Platform is the longer deck section that sits across the modular uprights to form a work platform. It lets the end user customise the platform length at variable heights and shapes to suit the application, and it increases safety and efficiency in the workplace. Because it is an off the shelf solution, there is no huge capital cost or long lead time. The system is designed for the transportation, aviation, manufacturing, warehousing, defence and mining industries, plus heavy equipment maintenance and stock picking.

Key Features

• Industrial rated for use on commercial and industrial sites
• Strong, fully welded design fabricated from heavy duty aluminium
• 200kg load rate per platform bay
• Highly manoeuvrable and lightweight
• Removable handrails for safe access to the work zone
• Foot operated castor brakes for stability when in position
• Supplied as a flat pack for optimal transporting
• Standard sized fasteners and included tools improve assembly time
• Easy to follow picture based instructions with an actual size bolt template
• Made to Australian Standard AS1892

Specifications

• Type: 2m platform system
• Material: aluminium
• Load rate: 200kg per platform bay
• Dimensions: 2060 x 650 x 115mm
• Weight: 31kg

Applications

• Warehouse and stock picking access
• Transportation, aviation and aircraft maintenance
• Manufacturing, process and heavy equipment maintenance
• Defence and mining industries

What You Need To Complete Your Access Platform Setup

Pair this platform with the right uprights to build a full work platform. Add a 3 step modular upright or a 5 step modular upright to support the deck, and a joiner platform to connect multiple bays. Browse the full Access Platform Ladder range for fixed platforms.

Frequently Asked Questions

What is the load rating of this platform?

The modular access system is rated at 200kg per platform bay, which covers the weight of a person plus tools and materials on each bay. The system is industrial rated for commercial and industrial sites and is made to Australian Standard AS1892. Always follow the manufacturer instructions for assembly and safe setup.

What does this platform do?

The 2.0m platform is the deck section that sits across the modular uprights. It gives you a longer standing surface than the 1.0m platform, so you can cover more of a racking run or work area with fewer bays. You can also connect multiple platforms with a joiner for an even longer walkway.

Is the system supplied assembled?

No. The modular access system is supplied as a flat pack for optimal transportation, with standard sized fasteners and the tools required for assembly included. Picture based instructions with an actual size bolt template make the build straightforward.

Can I build a platform at any length?

Yes. The modular system can be configured into any length work platform by combining uprights and platform bays. The platforms can also be stepped up or down, which lets you build a walkway that follows the level of the work area.

Can I order for delivery or pickup?

Yes. You can order online and choose Australia-wide delivery or pickup from our Truganina trade counter in Melbourne’s west. Some products are sourced to order, so there can be a 2 to 4 week lead time, and we send you a confirmation once your order is ready. For any questions call (03) 93941400 or email orders@singhroofingsupplies.com.au.
