Bailey Pro Deck Adjustable Wide Work Platform 150kg

The Bailey FS14200 Pro Deck is an adjustable wide work platform built for low level work that is too awkward to do off a ladder. The deck measures 1175mm x 500mm, which is enough to lay out tools and materials and to move along the work without stepping down. All four legs adjust independently through 175mm of vertical movement in 25mm increments, so the platform can be set level on a floor that is not, and the platform height runs from 550mm to 720mm. An auto locking mechanism disengages single handed, so setting up and packing down takes one person and no tools. The legs fold flat and there is a carry handle, so the unit travels and stores easily. The rating is 150kg at industrial duty and the platform is made to AS1892.

Key Features

• Large work deck measuring 1175mm x 500mm for secure footing and tool space
• All four legs adjust independently through 175mm of vertical movement in 25mm increments
• Auto locking mechanism with single handed disengagement action
• No-pinch adjustment knobs for quick height changes
• Legs fold flat for transport and storage, with an ergonomic carry handle
• 150kg load rating with an industrial duty classification
• Made to Australian Standard AS1892

Specifications

• Type: adjustable wide work platform
• Material: aluminium
• Platform size: 1175mm x 500mm
• Platform height: 550mm to 720mm
• Height adjustment: 175mm of vertical movement in 25mm increments
• Maximum reach height: 2.7m
• Load rating: 150kg
• Weight: 9.5kg
• Australian Standards: AS1892

Applications

• Low level work where the floor is uneven, sloped or stepped
• Ceiling, wall and partition work that needs a wide, stable deck
• Trade and industrial maintenance at working height
• Fit-out and finishing work where a ladder is the wrong tool

What You Need To Complete Your Work Platform Setup

For longer spans at height, pair it with an ALTECH Supasafe trestle and an aluminium plank in 4.0m or 5.0m. Browse the full Access Platform Ladder range for guarded platform options.

Frequently Asked Questions

What is the load rating of this work platform?

The FS14200 Pro Deck is rated to 150kg with an industrial duty classification, which covers a person plus tools and materials. Always confirm the total working load before use and follow the manufacturer instructions for safe setup.

How much adjustment does it have?

All four legs adjust independently through 175mm of vertical movement in 25mm increments, and the platform height runs from 550mm to 720mm. That range is what lets you set a level deck on a floor that slopes, steps or drains.

How heavy is it to carry?

It weighs 9.5kg. The legs fold flat and there is an ergonomic carry handle, so one person can move it around a site and load it without help.

What is the maximum reach height?

The maximum reach height is 2.7m. That places the platform in the low level working range, which is where a wide stable deck beats a step ladder for anything that takes more than a moment.

Can I order for delivery or pickup?

Yes. Order online for Australia-wide delivery or collect from our Truganina trade counter in Melbourne’s west. Some products are sourced to order, so there can be a 2 to 4 week lead time. Call (03) 93941400 or email orders@singhroofingsupplies.com.au with any questions.
