Thermoseal Extra Heavy Duty ResiWrap

The Thermoseal Extra Heavy Duty ResiWrap is a polyweave building membrane that wraps the wall frame before the cladding goes on. It is an extra heavy duty grade, which means it holds up to the weather on site while the build is still open, and it keeps doing a job after the house is finished by blocking wind-driven rain and dust. The reflective surface also adds an air-gap R-Value when it sits next to an air space, so it contributes to the thermal performance of the wall.

Key Features

• Extra heavy duty polyweave membrane for harsh site conditions
• Inward facing reflective surface adds an air-gap R-Value
• Protects the frame from weather before the roof and cladding go on
• Blocks wind-driven rain and dust as a secondary weather skin
• Meets BAL ember attack requirements under AS3959
• Flammability index of 5 or less tested to AS1530.2

Specifications

• Product: Thermoseal ResiWrap extra heavy duty
• Roll width: 1350mm
• Roll lengths: 30m (product code 108879, 40.5m² per roll) and 60m (product code 108004, 81m² per roll)
• Application: wall wrap behind brick veneer and other cladding
• Fire: flammability index 5 or less to AS1530.2
• BAL: meets ember attack requirements under AS3959

How It Works

ResiWrap goes on the outside of the frame, behind the cladding, with the reflective face positioned next to an air space. During construction it protects the frame from rain while trades work inside. Once the house is finished, it blocks wind-driven rain and dust, reduces draughts into the roof space and adds a reflective R-Value to the wall. In a wall without bulk insulation, the air gap generated by the wrap does the thermal work.

Applications

• Wall wrap behind exterior brick veneer walls
• Protecting the frame during construction
• Reducing draughts and improving energy efficiency
• BAL rated builds needing ember protection at the wall

What You Need To Complete The Job

Seal the laps and joins with reinforced foil tape so the membrane stays continuous. For the roof side of the build, pair it with a roof insulation blanket. Browse the Roof Insulation range for sarking and blankets.

Frequently Asked Questions

What is ResiWrap used for?

It is a wall wrap that goes behind brick veneer and other cladding to protect the frame. During construction it keeps the frame dry while trades work inside, and once finished it blocks wind-driven rain and dust from the wall cavity.

Does it add insulation value?

Yes. The inward facing reflective surface adds an air-gap R-Value when positioned next to an air space. In a wall without bulk insulation, the air gap in the frame generates the R-Value.

What rolls does it come in?

It comes in 1350mm wide rolls of 30m (40.5m², product code 108879) and 60m (81m², product code 108004). Order the roll length that matches the wall area of the build.

Is it suitable for bushfire-prone areas?

Yes. It meets the BAL ember attack requirements under AS3959 by providing a secondary form of ember protection, and it has a flammability index of 5 or less tested to AS1530.2.

Can ResiWrap be used as roof sarking?

ResiWrap is a wall wrap, so its main role is the wall cavity. During construction it protects the frame before the roof tiles go on, and it contributes a secondary ember skin for the roof space. For a dedicated roof underlay, use a roof sarking or an insulation blanket in the Roof Insulation range.
