Hytile Model A Tile Cutter

The Hytile Model A is a manual tile cutter built for roof tilers who cut concrete and terracotta tiles on site. It uses a chisel on top and a cutting wheel on the bottom, so the tile is scored from one side and snapped cleanly from the other. The design lets one person set up and operate the cutter without help, which keeps a one-man crew moving on the roof. Earlier Hytile cutters of this type have stayed in service for over 25 years, which is the reliability this machine is known for.

Key Features

• Chisel on top and wheel on bottom for fast, accurate cuts
• Single-person operation, no second set of hands needed
• Cuts concrete and terracotta roof tiles at any angle
• Ergonomic design reduces back strain and fatigue
• Impact-absorbing frame lowers arm and shoulder stress
• Built for years of service on the job site

Specifications

• Product: Hytile Model A tile cutter
• Cutting system: chisel on top, wheel on bottom
• Weight: 14.30 kg
• Dimensions: 75.0 x 35.5 x 57.5 cm
• Material: concrete and terracotta roof tiles
• Trimming tray: not included, sold separately

Cutting Performance

The dual-action cutting system scores the tile from the bottom while the chisel breaks it from the top, which produces a clean edge on concrete and terracotta tiles. The machine cuts at any angle, so you can form valleys, hips and mitres on the roof rather than cutting every tile on the ground. Because the operation is mechanical, the cut is repeatable and the tile breaks where you want it to.

Applications

• Cutting concrete and terracotta roof tiles on site
• Valley, hip and edge tiles that need angled cuts
• Roofing contractors and tile installers
• New builds and re-roofing work

What You Need To Complete The Job

Pair the Model A with the accessories that keep it cutting clean. Add a Hytile Trimming Tray to catch offcuts and keep the roof tidy, keep a Hytile cutter chisel and cutter wheel and pin as spares, and mark cut lines with a Hytile scriber. See the full Tile Roofing Tools range for more.

Frequently Asked Questions

Can one person operate the Model A?

Yes. The Model A is designed for single-person operation. The frame holds the tile while the cutting action scores and snaps it, so one operator can set the tile, cut it and move on without help.

What tiles does it cut?

It cuts concrete and terracotta roof tiles at any angle, including straight cuts, valley mitres and hip cuts. The dual chisel and wheel action suits the dense, brittle materials used in roof tiles.

Is the trimming tray included?

No. The trimming tray is sold separately. It catches tile offcuts and debris under the cutter, which keeps the roof and the work area tidy and reduces the slip hazard from loose tile pieces.

How long will the cutter last?

Earlier Hytile cutters of this type have remained in service for over 25 years. The heavy steel frame and simple mechanical action are built to be maintained on site by replacing the wear parts, the chisel, wheel and pins.

Can I order for delivery or pickup?

Yes. You can order online and choose Australia-wide delivery or pickup from our Truganina trade counter in Melbourne’s west. Delivery windows depend on your postcode, and we send a confirmation once your order is ready. For any questions call (03) 93941400 or email orders@singhroofingsupplies.com.au.
